3D pineapple lamp Full color waterproof and durable LED Christmas ball diamond crystal light
Product features:
3D Diamond Light is an innovative LED lighting product, whose design is inspired by the bright and three-dimensional sense of diamonds. The following is a detailed description of the 3D diamond light:
Appearance and structure:
3D diamond lights usually consist of multiple LED light beads arranged in a manner similar to the diamond cutting surface to form a three-dimensional light display frame.
The lamp beads can be independently controlled and can display different colors and brightness, creating a diamond-like glow effect through color and brightness changes.
The shell of the luminaire is usually made of a transparent material so that light can penetrate and show, while maintaining a beautiful and stylish appearance.
3D pineapple light technical parameters
| Basic product parameters | Product protection parameter |
| Product model | XQD-3D-XBL | Waterproof class | IP54 |
| Product size | Φ23mm*25mm | Shell flame retardant | V-0 |
| Application environment | Indoor | UV resistance grade | 4 |
| Product weight | About 3.5g | Salt spray test | Salt spray resistance |
| Shell material | PC | Impact resistance | IK10 |
| Maximum number of connections | 100PCS/string | Electrical safety class | Ⅲ class |
| Center distance | Minimum 5cm±0.5mm | Safety certification | CE FCC RoHs |
| Average product life | 50000h | Operating temperature | -40℃-55℃ |
| Optional accessories | T-terminal/crystal ball | Tensile strength | ≤6.5kg |
| Wire core | 4x0.25mm² | Instantaneous tensile strength | ≤25kg |
| Wire material | PVC | | |
| PCB material | FR-4 Fiberglass board | | |
| Product optical parameters | Electrical parameters of the product |
| LED color | RGB | Operating voltage | DC12V |
| Luminous Angle | 360° | Rated power | 0.72W |
| Color resolution | 3x8bit | Supporting system |
| Lamp bead | SMD3535*2LED | Control system | SPI |
| Pixel point luminous flux | 10.4lm | Power supply system | DC12V Constant voltage |
| luminance | 3.8cd | | |
Applications:
Widely used in billboards, highways, railway tunnels, bridges, squares, stadiums, trees, parking lots,
building walls, hotel, meeting room, offices , hospital , schools , factories , commercial lighting ,
shopping malls, supermarkets, kitchen, display, backlight and so on.
